Fundex Equipment B.V. designs, produces and supplies multifunctional foundation machines from Middelburg all over the world. More than 60 years of experience in the field of various foundation techniques is the basis for the development of all our products.

Large leaders up to 56 M long

High torque and pull up/down force

Multifunctional

Highlights

Full Displacement Drilling

CFA large diameter

Double Rotary Drilling Large Diameter

Soil Cutter Mixer

Pile Driving

Triple Soil Mixer

Applications

Fundex

The FUNDEX F4800 is the latest model in the range of FUNDEX multifunctional foundation rigs. The F4800 is special designed for both drilling and pile driving techniques, double drilling, soil mixing, sheet pile push pull system and vibratory hammer.

F4800

The FUNDEX CD20D is a compact foundation machine for making various piles in places where space and height are limited. Despite the compact design the machine is powerful and can be equipped with different rotary heads up to 200kNm. The four outriggers enable the machine to lift up and rotate the undercarriage in the driving direction to avoid spragging and damage to the working platform.

CD20

The FUNDEX F5600 is the largest model in the range of Fundex Equipment multifunctional foundation rigs. The F5600 can be used for both drilling and pile driving techniques, double drilling, soil mixing, sheet pile push pull system and vibratory


self-erecting
high stability thanks to both front and rear supports as well as a low centre of gravity
additional power pack with a 585 kW powerful Volvo engine
torque of 500 kNm along the entire leader length
the ergonomic cabin with modern control and monitoring system can be swiveled out which provides an optimum view on the job

F5600

F2500

F2800

F3500

Electric version available

48 meters leader

185 T weight

Multi-functional

self-erecting

front and rear supports (optional without front supports)

man lift along the entire leader length

Advantages

F4800 is powerful machine. 48 meters length allows various high capacity application. CFA possible up to 1500 m , it is impressive. Soil displacement is 914 mm but it is also possible to put a hammer for pile driving (25 tons hammer). Amazing and powerful multifunctional machine,

suitable for restricted access sites

rotary head stays on the machine during transport

broad scope of pile techniques including CFA, soil displacement and pile driving

extensive data acquisition system available with possibility to MYRIX access

Fundex CD20 is has an extremelly high power for the size. 200 kNm of torque and weights only 22 Tons.
It is possible to use it in a restricted area as well as low headroom areas (mast is secrional and can be removed). It can be used for various FDP applications , CFA etc.

Great quality machines!

Powerfull

I purchased this model a year ago, and it's been working flawlessly ever since. The performance is outstanding, and I haven't encountered any issues at all. It's reliable, efficient, and has exceeded my expectations in every way. From the design to the functionality, everything about this product is top-notch. I would highly recommend it to anyone looking for a dependable model that delivers consistent results. It's worth the investment, and I couldn't be more satisfied with my purchase. Overall, it is a fantastic product that has made my life so much easier!

Great Product

A remote controlled Fundex CD20 drill rig with 20 ton-meters of torque and 15 tons of crowd force is used to install the DeWaal Screw Piles. The rig has sectional leaders, which can be adjusted from 13 to 60-feet in length to accommodate various height restrictions.

Great compact rig
