Doosan HM1250 CNC Horizontal Machining Center Pallet Size: 49.2” x 49.2” Max Table Capacity: 11,023 lbs X Axis Travel: 82.8″ Y Axis Travel: 59″ Z Axis Travel: 59″ Spindle Taper: CAT50 Spindle Speed: 6000 RPM Rapid Traverse Rates (X,Y,Z): 945 IPM Cutting Feedrate: 1 – 472 IPM Magazine Capacity: 90 ATC Main Motor: 60 HP Floor Space w/Chip Conveyor: 458″ x 229″ x 160″ Weight: 69,445 lbs Options: 1 degree Turbo chip conveyor 1,000 fix psi chip blaster OMP60 part probe and tool setter 90 tools Cat50

Doosan HM1250 CNC Horizontal Machining Center Pallet Size: 49.2” x 49.2” Max Table Capacity: 11,023 lbs X Axis Travel: 82.8″ Y Axis Travel: 59″ Z Axis Travel: 59″ Spindle Taper: CAT50 Spindle Speed: 6000 RPM Rapid Traverse Rates (X,Y,Z): 945 IPM Cutting Feedrate: 1 – 472 IPM Magazine Capacity: 90 ATC Main Motor: 60 HP Floor Space w/Chip Conveyor: 458″ x 229″ x 160″ Weight: 69,445 lbs Options: 1 degree Turbo chip conveyor 1,000 fix psi chip blaster OMP60 part probe and tool setter 90 tools Cat50

Kiwa KH4500 CNC Horizontal Machining Center

Kiwa KH4500 CNC Horizontal Machining Center Specifications (subject to buyer verification): Movement And Ranges • Extended X-Axis Stroke ………………………………………………………… 27.6″ • Extended Y-Axis Stroke …………………………………………………………… 29.1″ • Z-Axis Travel ………………………………………………………………………….. 26.8″ TABLE (PALLET) • Pallet Working Surface ………………………………………………………………. 19.7″ x 19.7″(500mm Upgrade) • Maximum Workpiece Size – PC2 (Dia. X H) ………………………………….. Ø 29.5 x 39.4” • Pallet (Table) Loading Capacity …………………………………………………… 1,100 lbs. • Min. Table Indexing Angle ………………………………………………………….. .001 deg. SPINDLE • Spindle Motor …………………………………………………………………………… 50 HP • Spindle Speed Range ………………………………………………………………… 150-15,000 RPM • Type of Spindle Taper Hole ………………………………………………………… 40 Taper Big Plus • Tool Storage Capacity ……………………………………………………………….. 120 Tools Equipped With (subject to buyer verification): FANUC 31i-B CNC Control 150-15,000 RPM Spindle Speed 50 HP Spindle Motor 2 Pallet Changer Chip Conveyor (LNS Premium) Coolant Chip Flow System 500mm Pallet Upgrade (Both Pallets) Chip Blaster J-30 1000 PSI HPC System AICC II 1000 Block Look Ahead Upgrade 4 Spare M-Codes Renishaw Pop-Up Style Tool Length Measurement/Breakage Detection Probe Renishaw OMP400 Spindle Probe

2013 Makino A61NX

2013 Makino A61NX CNC HMC SPECIFICATIONS: X 28.7″ Y 25.6″ Z 31.5″ POWER 40 hp RPM 14,000 RPM # ATC 60 TAPER HSK63 PALLET-W 19.7″ PALLET-L 19.7″ # AXIS 4 CONTROL CNC (PRO 5) DIMENSIONS 225 in x 117 in x 131 in WEIGHT 37400 lbs EQUIPPED WITH: PRO 5 CONTROL BOX WAYS FULL 4TH AXIS THROUGH-SPINDLE COOLANT & AIR THROUGH (300 PSI) CHIP BLASTER UNIT 1000 PSI 14,000 RPM SPINDLE (HSK63) 60 TOOL POSITIONS CHIP CONVEYOR (LEFT DISCHARGE) 600 MACRO CUSTOM VARIABLES HIGH-SPEED SKIP FUNCTION HELICAL INTERPOLATION RIGID TAPPING NOTE: Tombstones in pictures do NOT go with machine
