HNK HB150S HBM – 2012
HNK HB150S HBM – 2012
Category
Boring Mills
Condition
Used
Location
990 Sunshine Lane Altamonte Springs, FL 32714
Brand
HNK
Model
HB150S HBM
Hours of Usage
-
Year of Manufacture
2012
View More Details
Interested in this product?
Contact the seller for price and availability.
Send Message to the Seller
Specifications
Used Cnc Brands
HNK
Spindle Diameter
5.9"
Taper
50
Spindle Motor
60 HP
X Axis Travel
255"
Y Axis Travel
118"
Z Axis Travel
63"
W Axis Travel
27.5"
Indexing
.001 Degree
Atc Stations
60 ATC
Description
HNK HB150S 5.9″CNC table type boring machine Table : 78.7″ x 86.8″ Table Load: 20 ton Table Indexing: 0.001 degree indexing X-Axis Travel: 255″ Y-Axis Travel: 118.1″ Z-Axis Travel: 62.99″ W-Axis Travel: 27.55″ Spindle dia : 5.9″ Taper: BT 50 taper Spindle Speed: 2000 rpm Spindle Motor: 50 / 60 HP Fanuc 31i-A control Scales 60 tool ATC Chip conveyor
Get in Touch with Seller About This Product
Similar Products
See AllKURAKI AKB-13 HBM – 2015
Kuraki
AKB-13 HBM
Boring Mills
USED
2015
Contact
KURAKI AKB13 CNC TABLE TYPE BORING Machine SPECIFICATIONS: Spindle Size 5.12″ X-Horizontal Travel of Table 118″ Y-Vertical Travel of Head 70.87″ Main Spindle Power 30 hp Spindle Speeds RPM 5- 3,000 RPM Table-W 62.99″ Table-L 70.87″ Max Loading Weight on Table 22,000 Lbs. DIMENSIONS 24 ft. x 23 ft. WEIGHT 77,000 Lbs EQUIPPED WITH: Fanuc Oi-MB CNC CONTROL Chip Blaster 1000 PSI High Pressure Thru-Spindle Coolant 60 Station Automatic Tool Changer Cogsdill ZX300-TC CAT 50 Taper Facing and Boring Tool Note: Best Available Machine & Options Subject Prior Sale! Machine Approx Weight 66,000. Lbs.
Kuraki
Boring Mills
USED
2015
NOMURA HBA 110T-R2 HBM – 2015 (Sold)
Nomura
HBA 110T-R2
Boring Mills
USED
2015
Contact
NOMURA HBA110T-R2 CNC Table Type Horizontal Boring Mill SPECIFICATIONS: TABLE SIZE: ……………………. 45″ X 45″ TABLE CAPACITY: ………………… 6,600 LBS SPINDLE DIAMETER: ………………. 4.33″ SPINDLE TAPER: …………………. CT-50 MAX SPINDLE SPEEDS: …………….. 3000 RPM SPINDLE MOTOR: …………………. 30 HP TRAVELS – X AXIS: ………………. 51.2″ – Y AXIS: ………………. 46.3″ – Z AXIS: ………………. 34.4″ – W AXIS ……………….. 15.7″ N/C ROTARY TABLE INDEXING: ………. 0.001 DEG/360,000 POSITION MAX. CUTTING FEEDRATE: ………….. 236 IPM RAPID TRAVERSE: ………………… 472 IPM TOOL CHANGER CAPACITY: ………….. 30 TOOLS
Nomura
Boring Mills
USED
2015
Mazak Mega Turn 500 VTL – 2015
Mazak
Mega Turn
Boring Mills
USED
2015
Contact
Mazak Mega Turn 500 CNC VTL Mazak Mega Turn 500 CNC VTL Specifications (subject to buyer verification): Capacity Max. swing: 27.56″ Max. machining diameter: 19.69″ Max. machining height: 18.19″ Max. loading capacity: 1100 lbs Stroke X axis: 13.5″ Z axis: 20.375″ Distance from spindle face to turret face: 6.5″ ~ 26.75″ Spindle Chuck size: Spindle speed: 3000 rpm Max. torque: 596 ft • lbs Min. indexing abgle increment (C axis) : 0.0001° Spindle nose: A2-11 Turret Type: 12-position drum turret (Bolt-on) Number of tools: 12 tools Tool shank (O.D.) : 1″ Tool shank (I.D.) : 2” Turret indexing time: 0.3 sec/1 step Feedrate Rapid traverse rate: X axis: 1181 IPM Rapid traverse rate: Z axis: 1181 IPM Rapid traverse rate: C axis: 75 rpm Motors Spindle motor: (40% ED/30-min. rating/Cont. rating) 35/30 H Power requirement Required power capacity: (30-min. rating/Cont. rating) 49.0/43.3 kVA Machine size Heigh: 117.72″ Floor space: 72.8″ x 93.3″ Machine weight: 20,400 lbs Equipped With (subject to buyer verification): Smart CNC Control 12 St. Turret Chip Conveyor
Mazak
Boring Mills
USED
2015
