Mazak QT Nexus 450-II x 1000u CNC Turning Center / QTN-450 / QTN450

Mazak QT Nexus 450-II x 1000u CNC Turning Center / QTN-450 / QTN450 Specifications (subject to buyer verification): MAXIMUM SWING……………………….33.25″ STANDARD MACHINING DIAMETER…………..13.22″ MAXIMUM MACHINING DIAMETER…22.80″ (ADJACENT POCKETS EMPTY) SPINDLE MOTOR…………………50/40 HP (30 MIN/CONT.) SPINDLE BORE………………………..7.2″ SPINDLE SPEED……………………….2,000 RPM NUMBER OF TOOLS……………………..12 Equipped With (subject to buyer verification): Mazatrol Matrix Nexus 2 Control Rear Chuck Prep A2-20 Nose Programmable Tailstock Re-Threading Thread Start Point Compensation Chip Conveyor Side 1000U (40”) Hinge 18” Air Chuck

Okuma Space Turn LB3000EXII-MYW/450 Multi-Axis CNC Lathe

Okuma Space Turn LB3000EXII-MYW/450 Multi-Axis CNC Lathe Catalogue Specifications Distance Between Centers: 17.7″ Distance Between Noses: 30.9″ Swing Over Bed: 22.8″ Swing Over Carriage: 18.5″ Max. Turning Diameter: 13.4″ Main-Spindle Spindle Diameter: 4.7″ Spindle Speed: 5,000 RPM (Infinitely Variable) Spindle Nose: JIS A2-6 Hole Through Spindle: 3.14″ Hole Through Actuator: 2.75″ Max. Workpiece Weight (Main-Spindle): 396 lb. Sub-Spindle Spindle Diameter: 3.9″ Spindle Speed: 6,000 RPM (Infinitely Variable) Spindle Nose: 5.5″ Flat Hole Through Spindle: 2.4″ Max. Workpiece Weight (Sub-Spindle): 242 lb. Motor: 30/20 HP (15min/cont.) Number of Turret Positions: 12 X-Axis Travel: 10.2″ Y-Axis Travel: 4.5″ Z-Axis Travel: 20.1″ W-Axis Travel: 23.4″ C-Axis Index: 360° (0.001° Increments) X-Axis Feedrate: 984 IPM Y-Axis Feedrate: 492 IPM Z-Axis Feedrate: 1,181 IPM W-Axis Feedrate: 1,181 IPM EQUIPPED WITH: Okuma OSP-P300LA CNC Control Kitagawa SR1670C Actuator Live & Static Tooling LNS Quick Six S2 Bar Feeder (2) Hardinge FLEXC 65 Collet Chucks LNS Chip Conveyor Absolent ODF-200S Mist Collector Parts Catcher

Hardinge T51SPMYT aka (T-51 Super Precision-MYT(B)) Multi-Axis CNC Turning Center

Hardinge T51SPMYT aka (T-51 Super Precision-MYT(B)) Multi-Axis CNC Turning Center Specifications (subject to buyer verification): Max Swing Over Way Covers: 29.88″ Max Machining Diameter (BMT-55) 12.35″ Max Machining Length with 8” Chuck (BMT-55): 16.85″ Max Machining Length with 20 C Collet (BMT-55): 22.47″ Max Spindle Speed: 5000 rpm Spindle Motor: 20-HP Cont. Spindle Torque: 256 Ft-Lb Spindle Nose: A2-6 Max Recommend Chuck: 8” Spindle Bore: 2.378” Bar Capacity: 2″ Turet Stations: 12-station + 1/2 station index Live Tooling Max Speed: 8,000-rpm Equipped With (subject to buyer verification): Fanuc Series 31iTB Tool Probe, Marposs (Includes Direct Measurement) Part Probe – Marposs (Includes High Speed Skip Software and Electrical) Part Program Storage 8MB
