Specifications for D-9 Grout Plant Model
Two Piece Mixing Tank
Round tank, bottom inclined to outlet Tank capacity: 230 l (60.84 U.S. gal) Hopper with bag ripper
Diesel drive
Three-cylinder Kubota Diesel Engine, Tier 4 Final, liquid-cooled 49.5HP Tank capacity approximately 83.28 l (22 U.S. gal) Starter battery
Frame
Skid mounted steel frame, partially encased
Forklift slots
Powder coat
Tools in Mixing Tank
High shear colloidal mixing element
Drive bearing above the mixing level
No packing seal, therefore runs dry without problems
Operating Elements
Two turning knobs for variable speed mixing
Turning knob for adjusting maximum pressure
Turning knob for changing speed of delivery rate (l/min/U.S. gal/min)
On/off switch for delivery pump (grouting pump)
2 x on/off button for semi-automatic water dosage (special equipment SA 7/2)
Similar Models
DT650 Mixing Station
Intric
0.0
No Rating
Based on 0 reviews
The DT650 Mixing Station brings performance and reliability to your large-scale grouting projects. Twin 30HP electric motors with twin 45-gallon hydraulic oil tanks drive a high-shear colloidal grout mixer, ready to perform under any specification. The DT650 is ready for recipe additives such as bentonite, water reducers, silica, or lime. Automatic features for water dosage, mixing and recipe are generated using load cells and onboard CPU. Check out the complete list of specs below!
D-12 Grout Plant
Intric
0.0
No Rating
Based on 0 reviews
he D-12 is the second model in the INTRIC line. Delivering 60 GPM capability up to 1800 PSI, it provides the additional capacities needed for larger micropiles and grouting projects. The D-12 has a 170 gallon storage tank and 60 gallon mixing tank capacities. INTRIC Grout Plants mix colloidally and high sheer which provides efficient speed to mix cement and has the ability for additional materials like sand, silica or lime to be added. Additionally, the data can be recorded and logged for volume of daily use or per pile volumes. FULLY AUTOMATIC MODEL with batch data recording also available! Check out the complete list of specs below.
The D-12 both sells and ships internationally, so its available when and where you need it.
DT650 Mixing Station
Intric
0.0
No Rating
Based on 0 reviews
The DT650 Mixing Station brings performance and reliability to your large-scale grouting projects. Twin 30HP electric motors with twin 45-gallon hydraulic oil tanks drive a high-shear colloidal grout mixer, ready to perform under any specification. The DT650 is ready for recipe additives such as bentonite, water reducers, silica, or lime. Automatic features for water dosage, mixing and recipe are generated using load cells and onboard CPU. Check out the complete list of specs below!
D-12 Grout Plant
Intric
0.0
No Rating
Based on 0 reviews
he D-12 is the second model in the INTRIC line. Delivering 60 GPM capability up to 1800 PSI, it provides the additional capacities needed for larger micropiles and grouting projects. The D-12 has a 170 gallon storage tank and 60 gallon mixing tank capacities. INTRIC Grout Plants mix colloidally and high sheer which provides efficient speed to mix cement and has the ability for additional materials like sand, silica or lime to be added. Additionally, the data can be recorded and logged for volume of daily use or per pile volumes. FULLY AUTOMATIC MODEL with batch data recording also available! Check out the complete list of specs below.
The D-12 both sells and ships internationally, so its available when and where you need it.
